Spare parts ultrasonic cleaner and spare parts cleaning machine designed for industrial performance and precision.
Main Features:
1. Stainless steel tank with wear resistance and long work life.
2. 6.5L capacity (1.7 gallon) with digital timer & heater control.
3. Includes stainless steel basket.
4. Compatible with tap water, industrial alcohol, or solvent cleaners.
Advanced Control:
5. Industrial microcontroller chip with flexible circuit board control.
6. Temperature tunable from 20°C to 80°C.
7. Certified by CE & RoHS.
Applied Industries:
Electronics, machinery, auto industry, motor industry, optical industry, watchmaker, jewelry maker, plating & painting, food industry, medical & pharmacy, textile industry, and household use.
⚙
Technical Specifications
| Ultrasonic Frequency | 40,000 Hz |
| Material | Stainless Steel SUS304 |
| Tank Capacity | 6.5 L |
| Timer | 1-30 minutes, Digital timer |
| Power Supply | AC 100~120V / 220~240V, 50/60Hz |
| Ultrasonic Power | 180W |
| Heating Power | 150 W, Digital Heating |
| Unit Size | 325 x 180 x 280 mm |
| Tank Size | 300 x 150 x 150 mm |
| Net Weight | 6.0 kg |
?
Frequently Asked Questions
What are the advantages of an ultrasonic cleaner over traditional methods?
It minimizes manual labor, enables cleaning without organic solvents, reaches difficult areas to remove all types of dirt, and shortens extraction and purification processes.
What frequency is better for my parts?
28kHz is stronger for heavy parts (car/motor parts) to remove oils and grease. 40kHz is better for PCBs and electronic parts. Higher precision requires higher frequency.
Can ultrasonic cleaning damage parts?
The process is safe. While powerful, the implosions are at a microscopic level and do not damage daily objects.
What cleaning solution should I use?
Selection depends on the application. Proper formulas prevent unwanted reactions and ensure acceptable cleaning activity.
Is rinsing required after cleaning cycles?
Yes, rinsing is recommended to remove chemical residues. You can use a clean water bath, tap water, or deionized water.
What is the voltage compatibility?
The units can be configured for AC110V single phase or AC220V/380V three phase depending on your requirements.
